Parent Layer: Storm Sewer

Name: Storm Inlets

Display Field: FACILITYID

Type: Feature Layer

Geometry Type: esriGeometryPoint

Description: <DIV STYLE="text-align:Left;"><DIV><DIV><P><SPAN>Entry points into the storm water system which utilize storm mains that lead to the waterways. May end in an outfall, a leaching basin/drywell, or a storm pond.</SPAN></P><P><SPAN>Curbside grate - square grate with a curb opening, at the curb of a roadway.</SPAN></P><P><SPAN>Round inlet grate - flat round grate with large (usually slotted) openings for stormwater to enter.</SPAN></P><P><SPAN>Square inlet grate - square slotted grate, without curb opening. Can be found at junctions of areas with similar heights (i.e. roadway to driveway).</SPAN></P><P><SPAN>Beehive - round grate that is dome-shaped.</SPAN></P><P><SPAN>Rectangular inlet grate - long slotted grate. Uncommon.</SPAN></P><P><SPAN /></P><P><SPAN>Ownership clarification: </SPAN></P><P><SPAN>1. On county map: CCDC (drain commissioner) owns these</SPAN></P><P><SPAN>2. In ROW: Battle Creek owns</SPAN></P><P><SPAN>3. Outside of Battle Creek: Calhoun County owns</SPAN></P><P><SPAN>4. Private property: owner, except if it is draining to a pond Battle Creek maintains, then Battle Creek owns it. Check with Engineering Department</SPAN></P></DIV></DIV></DIV>

Copyright Text: Originally created by Woolpert Inc. in 1997. Edited by Battle Creek DPW Records Division.

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 20000

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: false

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: -9495355.504635816
YMin: 5197907.864951784
XMax: -9477220.846024005
YMax: 5216581.4053460825
Spatial Reference: 102100  (3857)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• FACILITYID ( type: esriFieldTypeString, alias: FACILITYID, length: 10 )
• GraniteXP_ID ( type: esriFieldTypeString, alias: GraniteXP_ID, length: 10 )
• FEATURE ( type: esriFieldTypeString, alias: FEATURE, length: 20 )
• SUBTYPE ( type: esriFieldTypeString, alias: SUBTYPE, length: 20 , Coded Values: [CURBSIDE GRATE: Curbside Grate] , [INLET: Inlet] , [RND. INLET GRATE: Round Inlet Grate] , ...5 more... )
• EASTING ( type: esriFieldTypeDouble, alias: EASTING )
• NORTHING ( type: esriFieldTypeDouble, alias: NORTHING )
• MUNICIPALITY ( type: esriFieldTypeString, alias: MUNICIPALITY, length: 20 , Coded Values: [Bedford Township: Bedford Township] , [City of Battle Creek: City of Battle Creek] , [City of Springfield: City of Springfield] , ...7 more... )
• OWNERSHIP ( type: esriFieldTypeString, alias: OWNERSHIP, length: 50 , Coded Values: [Private: Private] , [City of Battle Creek: City of Battle Creek] , [Calhoun County Drain Commission: Calhoun County Drain Commission] , ...4 more... )
• GPS_Date ( type: esriFieldTypeDate, alias: GPS_Date, length: 8 )
• Verified ( type: esriFieldTypeString, alias: Verified, length: 8 , Coded Values: [N: No] , [Y: Yes] , [N/A: N/A] )
• DRAINS_TO ( type: esriFieldTypeString, alias: Connects To, length: 50 )
• DRAINAGE_DISTRICT ( type: esriFieldTypeString, alias: DRAINAGE_DISTRICT, length: 20 )
• SURFACE_ELEVATION ( type: esriFieldTypeDouble, alias: SURFACE_ELEVATION )
• YEAR_INSTALLED ( type: esriFieldTypeSmallInteger, alias: YEAR_INSTALLED )
• CONTRACTOR ( type: esriFieldTypeString, alias: CONTRACTOR, length: 20 , Coded Values: [City of Battle Creek: City of Battle Creek] , [Crest Construction: Crest Construction] , [Hoffman Brothers: Hoffman Brothers] , ...10 more... )
• DEPTH ( type: esriFieldTypeDouble, alias: DEPTH )
• CONDITION ( type: esriFieldTypeString, alias: CONDITION, length: 20 )
• COMMENTS ( type: esriFieldTypeString, alias: COMMENTS, length: 100 )
• D_STICKER ( type: esriFieldTypeString, alias: D_STICKER, length: 3 )
• STICKER_DATE ( type: esriFieldTypeSmallInteger, alias: STICKER_DATE )
• Duplicates ( type: esriFieldTypeSmallInteger, alias: Duplicates )
• Structure_Code ( type: esriFieldTypeString, alias: Structure_Code, length: 50 )
• PWTYPE ( type: esriFieldTypeString, alias: PWTYPE, length: 10 )
• Enabled ( type: esriFieldTypeSmallInteger, alias: Enabled , Coded Values: [0: False] , [1: True] )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• CreatedBy ( type: esriFieldTypeString, alias: Created By, length: 150 )
• CreatedByDate ( type: esriFieldTypeDate, alias: Created By Date, length: 8 )
• EditedBy ( type: esriFieldTypeString, alias: Edited By, length: 150 )
• EditedByDate ( type: esriFieldTypeDate, alias: Edited By Date, length: 8 )
• MaintainedBy ( type: esriFieldTypeString, alias: Maintained By, length: 75 , Coded Values: [Bedford Township: Bedford Township] , [City of Battle Creek: City of Battle Creek] , [City of Springfield: City of Springfield] , ...7 more... )
• ConnectedOutfall ( type: esriFieldTypeString, alias: ConnectedOutfall, length: 100 )
• Inspection_Complete ( type: esriFieldTypeString, alias: Inspection_Complete, length: 255 , Coded Values: [Yes: Yes] , [No: No] )
• Inspection_Date ( type: esriFieldTypeDate, alias: Inspection_Date, length: 8 )

Supported Operations:   Query   Query Attachments   Query Analytic   Generate Renderer   Return Updates

  Iteminfo   Thumbnail   Metadata
